Marsh Nickel Alloys, based in Canberra, Australia, proudly serves as a trusted partner for industries in Canberra, Australia, seeking the exceptional qualities of Waspalloy sheet and plate. We understand the demanding environments you operate in, which is why our supply chain is built on reliability and a deep technical understanding of high-performance materials. Our commitment is to provide not just a product, but a dependable solution that meets the rigorous standards required for your most critical applications, ensuring your projects are built on a foundation of proven strength and durability.
Waspalloy’s remarkable strength comes from its sophisticated composition, primarily nickel, chromium, and cobalt, which is further enhanced with aluminum and titanium. This specific blend gives the sheets and plates outstanding mechanical properties, including exceptional tensile strength and impressive resistance to creep and fatigue. Even when subjected to the intense heat common in aerospace and power generation, it maintains its structural integrity, making it a go-to material for components that simply cannot afford to fail under extreme pressure and temperature.
| Specification : | AMS, AMS, API |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Size : | 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Waspaloy (UNS-N07001) |
| STANDARD | UNS | Material No |
| Waspaloy | N07001 | 2.4654 |
| Waspaloy | Cr | Ni | Mo | Co | Al | Ti | B | C | Zr | Fe | Mn | Si | P | S | Cu |
| MIN | 18.00 | — | 3.50 | 12.00 | 1.20 | 2.75 | 0.003 | 0.02 | 0.02 | — | — | — | — | — | — |
| MAX | 21.00 | Balance | 5.00 | 15.00 | 1.60 | 3.25 | 0.01 | 0.10 | 0.08 | 2.00 | 0.10 | 0.15 | 0.015 | 0.015 | 0.10 |
| Temperature, °F | Ultimate Tensile Strength, ksi | 0.2% Yield Strength, ksi | Elongation, % | Hardness, Rockwell C |
| 70 | 193 | 132 | 27 | 34-40 |
| 1200 | 173 | 112 | 21 | – |
| 1400 | 140 | 112 | 12 | – |
| 1600 | 79 | 60 | 12 | – |
The primary use for Waspalloy sheet and plate is in the heart of gas turbine engines, where it forms critical components like turbine blades and discs that must withstand searing temperatures and centrifugal forces. Beyond aerospace, its applications are vital in the power generation sector for industrial gas turbines and within the chemical processing industry for equipment exposed to highly corrosive environments. Essentially, wherever there is a need for a material that won’t back down from extreme heat and stress, Waspalloy provides the reliable performance that engineers and manufacturers in Canberra depend on.
Contact us to get a quick quote for your requirement.
Waspalloy Sheets and Plates are widely used in industries requiring high-temperature strength and corrosion resistance. They are essential in aerospace applications, including turbine blades, combustion chambers, and afterburner components, due to their exceptional performance under extreme heat. In the power generation sector, they are employed in gas turbines and heat exchangers. The chemical processing industry utilizes them for equipment exposed to harsh environments, such as reactors and pressure vessels. Additionally, Waspalloy’s durability and reliability make it suitable for industrial furnaces and high-performance fasteners. Their versatility and superior mechanical properties ensure optimal performance in demanding applications across various industries.
