Marsh Nickel Alloys is a well-respected manufacturer and supplier located in Canberra, Australia, known for its top-notch **Titanium Grade 2 Tube Fittings**. With a strong focus on precision engineering and outstanding performance, the company provides tube fittings that excel in corrosion resistance, strength, and durability. Marsh Nickel Alloys serves a diverse array of industries, including chemical processing, marine, and aerospace. Their **Titanium Grade 2 Tube Fittings** are crafted to meet international standards, guaranteeing reliability, leak-free operation, and a long lifespan, even in the toughest conditions.
**Titanium Grade 2 Tube Fittings** are mainly made of titanium, with trace amounts of iron and oxygen, striking a perfect balance between strength and ductility. This material boasts a tensile strength of about 345 MPa and a yield strength of roughly 275 MPa. With an elongation of 20%, it offers excellent formability and weldability. Additionally, Titanium Grade 2 provides exceptional resistance to oxidizing and mildly reducing environments, making it a great choice for applications that demand lightweight strength and impressive corrosion resistance.
| Specifications | ASTM B366 / ASME SB366 |
|---|---|
| Size | 1/16 in. to 2 in. & 2mm to 50 mm. |
| Dimensional Range | 1/16 to 2 inches (imperial); 2 to 50 mm (metric) |
| Working Pressures | Upto 2000 to 6000 PSI |
| Thread Type | NPT – ASME B1.20.1, SAE AS71051 | ISO/BSP Parallel – ISO 228 | ISO/BSP Tapered – ISO 7, BS EN 10226-1 | SAE (Unified) – ASME B1.1 |
| End Connections | NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Max Working Pressure | 8MPa | 1200psi Depending on The Tubing Material |
| Working Temperature | -40°C—250°C | -40°F—482°F Depending on The Tubing Material |
| Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
| Tube Fitting uses & application |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Grade 2 Tube Fittings in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
**Titanium Grade 2 Tube Fittings** find their place in various industries where corrosion resistance and high performance are essential. These fittings are commonly used in chemical processing plants, desalination facilities, marine engineering, aerospace systems, and the manufacturing of medical equipment. They are perfect for connecting tubes in heat exchangers, condensers, and hydraulic systems that operate under high pressure or in corrosive environments. Thanks to their biocompatibility, they are also employed in pharmaceutical and food processing applications, ensuring safety and purity in fluid transfer systems.
