Marsh Nickel Alloys, a leading manufacturer and supplier based in Canberra, Australia, proudly offers Titanium Grade 5 Tubing. Renowned for its exceptional strength-to-weight ratio and outstanding corrosion resistance, Titanium Grade 5 is ideal for high-performance applications in aerospace, marine, and industrial sectors. Our tubing is meticulously crafted to meet rigorous industry standards, ensuring durability and reliability in even the most demanding environments. TrustMarsh Nickel Alloys for top-quality Titanium Grade 5 Tubing solutions.
Titanium Grade 5 tubing is made up of 90% titanium, 6% aluminum and 4% vanadium. This alloy boasts an exceptional strength-to-weight ratio, with tensile strengths of up to 140 ksi (965 MPa) and yield strengths of 130 ksi (895 MPa) Provides excellent strength a corrosion resistance, high temperature performance and excellent fatigue, making it ideal for aerospace, automotive and industrial applications And combined with its lightweight nature it offers great advantages in harsh environments, enhancing performance and longevity increases in critical applications
| Specifications | : | ASTM B163, B516 / ASME SB163, B516 |
| Dimensions | : | ASTM, ASME and API |
| Tubes Size | : | 6 mm OD x 0.7 mm to 50.8 mm OD x 3 mm thk. |
| Schedule | : | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | : | Seamless / ERW / Welded / Fabricated / LSAW Tubes |
| Form | : | Round, Square, Rectangular, Hydraulic Etc |
| Length | : | Single Random, Double Random & Cut Length. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade 5 | 90 min | 0.1 max | 0.4 max | 0.015 max | 0.05 max | 0.20 max | 5.5-6.75max | 3.5-4.5 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Gr 5 Tubing in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium grade 5 tubing is widely used in the aerospace, automotive and marine industries due to its high strength-to-weight ratio and excellent corrosion resistance Typically, it is used in aircraft components, construction parts and engine parts for applications in high-performance automotive parts and marine equipment besides medical implants, prosthetics f Applications, where strength and biocompatibility are important. Its versatility and durability make it a desirable choice for rugged applications in a variety of industries.
