Marsh Nickel Alloys, located in Canberra, Australia, has built a solid reputation as a reliable manufacturer and supplier of high-performance Super Duplex Steel Stud Bolts S32760. These stud bolts are celebrated for their remarkable strength, resistance to corrosion, and long-lasting durability, making them perfect for even the toughest industrial settings. Marsh Nickel Alloys blends cutting-edge metallurgical knowledge with precise manufacturing techniques to produce items that adhere to international quality standards. Their dedication to excellence guarantees dependable performance in critical applications, offering customers robust fastening solutions that thrive in extreme temperatures, high pressures, and harsh chemical environments—truly essential for modern engineering projects.
Super Duplex Steel Stud Bolts S32760 are primarily made of iron, enriched with significant amounts of chromium (25–26%), nickel (6–7%), and molybdenum (3–4%), along with a touch of nitrogen to boost strength and corrosion resistance. This alloy showcases impressive mechanical properties, boasting a tensile strength of around 930–1000 MPa and a yield strength of about 620–690 MPa. Its superior resistance to pitting, crevice corrosion, and stress corrosion cracking makes it a great fit for challenging environments. The blend of high toughness, hardness, and fatigue resistance ensures that S32760 stud bolts keep their structural integrity even under extreme operational conditions.
| Specification | ASTM F593, F594, F1554 / ASME SF593, F594, F1554 |
| Standard | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Monel Monel® Alloy 400 Stud nuts length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Monel Alloy 400 Hex nuts |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Length | 3 mm to 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Packing | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Cadmium Coating Hot Dipped Galvanizing Coating Ptfe Coated Nickel Alloy 200 Fasteners Phosphate Coating Teflon Coating Xylon Coating Zinc Coating |
| Grade | C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
| Super Duplex Steel Stud Bolts S32760 | 0.030 max | 0.24 – 0.32 | 0.035 max | 0.80 max | 1.20 ma | 3.0 – 5.0 | – | 24.0 – 26.0 | 0.020 max | 6.00 – 8.00 |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Super Duplex Steel Stud Bolts S32760 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Steel Stud Bolts S32760 in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Steel Stud Bolts S32760 find their place in various industries that demand top-notch corrosion resistance and mechanical performance. They’re perfect for oil and gas platforms, chemical processing plants, petrochemical refineries, and marine applications where exposure to chloride-rich environments and high pressures is the norm. These stud bolts are also utilized in desalination plants, power generation facilities, and water treatment systems. Their ability to maintain strength and reliability in extreme conditions makes them vital for flanged connections, pressure vessels, and pipelines.
