Marsh Nickel Alloys is a leading manufacturer and supplier of Super Duplex Steel Stud Bolts S32750 in Canberra, Australia. Renowned for their exceptional strength and corrosion resistance, our S32750 stud bolts are designed to meet the stringent demands of various industries, including oil and gas, chemical processing, and marine applications. With a commitment to quality and precision, we ensure that each stud bolt delivers superior performance in harsh environments, offering reliable and long-lasting fastening solutions. As a trusted supplier,Marsh Nickel Alloys is dedicated to providing high-quality products that adhere to international standards, ensuring that our clients receive the best-in-class solutions for their critical applications.
| Specification | ASTM F593, F594, F1554 / ASME SF593, F594, F1554 |
| Standard | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Monel Monel® Alloy 400 Stud nuts length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Monel Alloy 400 Hex nuts |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Length | 3 mm to 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Packing | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Cadmium Coating Hot Dipped Galvanizing Coating Ptfe Coated Nickel Alloy 200 Fasteners Phosphate Coating Teflon Coating Xylon Coating Zinc Coating |
| Grade | C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
| Super Duplex Steel Stud Bolts S32750 | 0.030 max | 0.24 – 0.32 | 0.035 max | 0.80 max | 1.20 ma | 3.0 – 5.0 | – | 24.0 – 26.0 | 0.020 max | 6.00 – 8.00 |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Super Duplex Steel Stud Bolts S32750 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
**Super Duplex Steel S32750**, also referred to as UNS S32750 or SAF 2507, is a high-performance alloy made up of nearly equal parts of austenite and ferrite, along with chromium (25%), molybdenum (4%), and nickel (7%). This unique blend provides the stud bolts with remarkable strength and excellent resistance to pitting, crevice corrosion, and stress corrosion cracking—particularly in environments rich in chlorides. S32750 stud bolts boast high tensile and yield strength, outstanding fatigue resistance, and exceptional performance in challenging offshore and chemical conditions.
Contact us to get a quick quote for your requirement.
Marsh Nickel Alloys’ Super Duplex Steel S32750 stud bolts are extensively utilized in **oil and gas platforms**, **petrochemical plants**, **desalination facilities**, **marine engineering**, and **chemical processing** systems. Their capability to endure extreme pressures, high salinity, and harsh chemicals makes them perfect for critical bolted connections in structural and piping systems. Whether it’s for flanges, pressure vessels, or subsea equipment, the S32750 stud bolts from Marsh Nickel Alloys provide unparalleled strength and reliability for demanding industrial applications in Canberra and beyond.
