Home > Rene 41 Sheets and Plates
Marsh Nickel Alloys remains a trusted name in manufacturing and supplying high performance nickel alloys in Canberra, Australia. Known for its accuracy and quality, the company specializes in providing premium products such as René 41 Sheets and Plates. Made from high strength, heat resistant alloys, these sheets and plates are ideal for aerospace, chemical and industrial applications.Marsh Nickel Alloys is committed to excellence, ensuring sustainability and reliability for its global customers.
Marsh Nickel Alloys, located in Canberra, Australia, is a reliable manufacturer and supplier of top-notch nickel-based products, with a focus on Rene 41 Sheets and Plates. Known for their precision engineering and outstanding quality, this company caters to essential industries where strength, heat resistance, and reliability are crucial. Their Rene 41 Sheets and Plates are crafted to excel in extreme conditions, making them perfect for aerospace, power generation, and high-temperature applications. Marsh Nickel Alloys is dedicated to providing materials that adhere to strict industry standards while ensuring prompt delivery and exceptional customer service throughout Australia and beyond.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
Rene 41 Sheets and Plates are nickel-based superalloys primarily made up of nickel (around 55%), along with notable amounts of chromium (approximately 19%), cobalt (about 11%), molybdenum (close to 10%), titanium (around 3%), and aluminum (roughly 1.5%). These components offer remarkable oxidation resistance and strength at temperatures reaching up to 980°C (1800°F). Rene 41 boasts impressive tensile strength (up to 180 ksi), yield strength (around 140 ksi), and excellent creep resistance. The alloy is age-hardened to enhance its mechanical performance, making it ideal for applications that require both thermal and structural stability.
Contact us to get a quick quote for your requirement.
Rene 41 Sheets and Plates find extensive use in aerospace, especially in jet engine components, afterburner parts, and turbine casings, thanks to their high-temperature strength and oxidation resistance. In the power generation sector, they are utilized in gas turbines and high-performance heat exchangers. Their ability to maintain mechanical properties under thermal stress makes them perfect for rocket engine parts and other high-heat environments. Additionally, Rene 41 is employed in defense and nuclear industries for critical hardware that faces extreme conditions. Its durability, strength, and corrosion resistance make it a top choice for engineers seeking superior performance in challenging environments.
