Marsh Nickel Alloys is a leading manufacturer and supplier based in Canberra, Australia, specializing in high quality nickel alloys and related products Committed to excellence the company offers a wide range of known Rene 41 foil it as exceptional strength, corrosion resistance and high temperature performance include for , meanwhile Ensures delivery and customer service, and making them a reliable partner for any alloying needs in the region.
Marsh Nickel Alloys stands out as a leading manufacturer and supplier of **Rene 41 foil** in Canberra, Australia. With a focus on high-performance nickel-based superalloy materials, they provide precision-processed Rene 41 foil that boasts remarkable strength and heat resistance. Crafted to adhere to stringent aerospace and industrial standards, these foils are perfect for applications that demand durability in high-temperature settings. Known for their commitment to quality, timely delivery, and technical know-how, Marsh Nickel Alloys is a trusted name in Canberra, serving industries like aerospace, power generation, and high-temperature industrial processes.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
**Rene 41** is a nickel-cobalt-based superalloy celebrated for its impressive mechanical properties at temperatures reaching up to 700°C (1292°F). It features a blend of alloying elements such as **chromium, molybdenum, titanium, aluminum, and cobalt**, which contribute to its excellent creep resistance, oxidation resistance, and tensile strength. The foil form ensures a consistent thickness and superior surface quality, making it ideal for precision manufacturing and component fabrication.
Contact us to get a quick quote for your requirement.
| Grade | UNS | Workstoff | AMS | GE |
| Rene 41 | N07041 | 2.4973 | AMS 5545, AMS 5712, AMS 5713, AMS 5800 | GE B50TF109, GE B50TF76 |
Marsh Nickel Alloys’ Rene 41 foil finds extensive use in **gas turbine engines**, **rocket motors**, **aerospace structural components**, and **heat exchangers**. Its ability to maintain mechanical integrity under thermal stress makes it a vital choice for high-temperature environments. Marsh Nickel Alloys guarantees that every batch of Rene 41 foil meets strict specifications, bolstering Canberra’s advanced manufacturing and engineering sectors with top-notch superalloy solutions.
