Marsh Nickelalloys is a trusted manufacturer and supplier of high-quality Nimonic 90 Sheets and Plates in Canberra, Australia. Nimonic 90 is a nickel-based superalloy known for its excellent strength, oxidation resistance, and high-temperature stability, making it suitable for demanding applications in aerospace, gas turbines, and industrial sectors. These sheets and plates provide superior performance under extreme conditions, offering excellent mechanical properties such as high tensile strength and resistance to creep. We offer a wide range of Nimonic 90 products tailored to meet specific customer requirements, ensuring the highest standards of quality and reliability.
Marsh Nickel Alloys stands out as a reliable **manufacturer and supplier of Nimonic 90 sheets and plates** in Canberra, Australia. We focus on high-performance nickel-based superalloys that are built to withstand extreme temperatures and stress. Nimonic 90 is celebrated for its remarkable **creep resistance, oxidation stability, and mechanical strength** at temperatures soaring up to 980°C, making it a top choice for aerospace, power generation, and high-temperature industrial applications. At Marsh Nickel Alloys, we provide precision-engineered sheets and plates that adhere to strict international standards, ensuring dependable performance in Canberra’s demanding industries.
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Plate, Sheet and Strip : | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208 |
| Grade | Ni | Cr | Co | Ti | Al | C | Si | Cu | Fe | Mn | B | S | Zr | Pb |
| Nimonic 90 | Bal | 18-21 | 15-21 | 2-3 | 1-2 | 0.2 max | 1.0 max | 0.2 max | 1.5 max | 1.0 max | 0.02 max | 0.015 max | 0.15 max | 0.0020 max |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 1150 MPa | 725 MPa | 30% |
| Grade | Density | Specific Gravity | Specific Heat (Btu/lb/Deg F – [32-212 Deg F]) | Electrical Resistivity (microhm-cm (at 68 Deg F) | Melting Point (Deg F) |
| Alloy 90 | 8.18g/cm³ | 1370°C | 12.7 μm/m °C (20 – 100°C) | 82.5 kN/mm² | 213 kN/mm² 227 / 240 kN/mm² |
| 0.296 lb/in³ | 2500°F | 7.1 x 10-6 in/in °F (70 – 212°F) | 11966 ksi | 30894 ksi 32924 / 34810 ksi |
| STANDARD | WERKSTOFF NR. | UNS |
| Nimonic 90 | 2.4632 | N07090 |
Our Nimonic 90 sheets and plates boast outstanding resistance to **thermal fatigue, corrosion, and high-cycle stress**, all while maintaining dimensional stability and mechanical integrity in tough operating conditions. The alloy is crafted from a blend of nickel, chromium, cobalt, titanium, and aluminum, which work together to enhance its strength and oxidation resistance. These materials find extensive use in **gas turbines, combustion chambers, exhaust systems, and heat exchangers**.
Contact us to get a quick quote for your requirement.
Marsh Nickel Alloys offers Nimonic 90 sheets and plates in a variety of thicknesses, sizes, and surface finishes, all manufactured to meet standards like **AMS 5596, ASTM B435, and ISO 9001**. With customizable options and rigorous quality control, we proudly support Canberra’s aerospace, energy, and industrial sectors with top-notch Nimonic 90 flat products that deliver exceptional durability and performance.
