Marsh Nickelalloys is a trusted manufacturer and supplier of high-quality Nimonic 75 sheets and plates in Canberra, Australia. These advanced alloys are designed to perform under extreme temperatures and corrosive conditions, making them ideal for demanding applications in aerospace, gas turbines, and other high-stress environments. Nimonic 75 offers excellent mechanical properties, including high strength, outstanding creep resistance, and superior oxidation resistance. We provide a wide range of Nimonic 75 Sheets and Plates tailored to meet the specific needs of our customers, ensuring the highest standards of quality and performance.
Marsh Nickel Alloys, located in Canberra, Australia, has earned a solid reputation as a reliable manufacturer and supplier of high-performance nickel-based alloys. They offer a wide array of products, including Nimonic 75 Sheets and Plates. With a strong focus on quality, precision, and timely delivery, Marsh Nickel Alloys serves various industrial sectors both in Australia and around the globe. Their Nimonic 75 Sheets and Plates are specifically designed to meet rigorous standards, making them perfect for high-temperature and high-stress applications. Thanks to decades of metallurgical expertise and a customer-first mindset, Marsh Nickel Alloys has established itself as a trusted source for durable and corrosion-resistant alloy solutions.
| Standards : | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Plate, Sheet and Strip : | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208 |
| Grade | C | Mn | Si | Cu | Fe | Ni | Cr | Ti |
| Nimonic 75 | 0.08-0.15 | 1.0 max | 1.0 max | 0.5 max | 5.0 max | Bal | 18.0-21.0 | 0.2-0.6 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.37g/cm3 | 1340 – 1380 | Psi – 104,000 | Psi – 40,000 | 42 % |
| Grade | Density | Melting Point |
| Nimonic 75 | 8.4 g/cm3 | 1374°C-1420 °C |
| WEIGHT PER NIMONIC SHEET : | ||||
| THICKNESS IN MM | SIZE IN MM | WEIGHT KG/M2 | ||
| 2000 X 1000 | 2500 X 1250 | 3000 X 1500 | ||
| 0.18 | 2.88 | – | – | 1.44 |
| 0.20 | 3.20 | – | – | 1.60 |
| 0.22 | 3.52 | – | – | 1.76 |
| 0.24 | 3.84 | – | – | 1.92 |
| 0.27 | 4.32 | – | – | 2.16 |
| 0.28 | 4.48 | – | – | 2.24 |
| 0.32 | 5.12 | – | – | 2.56 |
| 0.38 | 6.08 | – | – | 3.04 |
| 0.44 | 7.04 | 11.00 | – | 3.52 |
| 0.50 | 8.00 | 12.50 | – | 4.00 |
| 0.56 | 8.96 | 14.00 | – | 4.48 |
| 0.63 | 10.08 | 15.75 | – | 5.04 |
| 0.75 | 12.00 | 18.75 | – | 6.00 |
| 0.88 | 14.08 | 22.00 | – | 7.04 |
| 1.00 | 16.00 | 25.00 | 36.00 | 8.00 |
| .1.13 | 18.08 | 28.25 | 40.00 | 9.04 |
| 1.25 | 20.00 | 31.25 | 45.00 | 10.00 |
| 1.38 | 22.03 | 34.50 | 50.00 | 72.00 |
| 1.50 | 24.00 | 37.50 | 54.00 | 12.00 |
| 1.75 | 28.00 | 43.75 | 63.00 | 14.00 |
| 2.00 | 32.00 | 50.00 | 72.00 | 16.00 |
| 2.25 | 36.00 | 56.25 | 81.00 | 18.00 |
| 2.50 | 40.00 | 62.50 | 90.00 | 20.00 |
| 2.75 | 44.00 | 68.75 | 99.00 | 22.00 |
| 3.00 | 48.00 | 75.00 | 108.00 | 24.00 |
| 3.25 | 52.00 | 81.25 | 117.00 | 26.00 |
| 3.50 | 56.00 | 87.50 | 126.00 | 28.00 |
| 3.75 | 60.00 | 93.75 | 135.00 | 30.00 |
| 4.00 | 64.00 | 100.00 | 144.00 | 32.00 |
| 4.25 | 68.00 | 106.25 | 153.00 | 34.00 |
| 4.50 | 72.00 | 112.50 | 162.00 | 36.00 |
| 5.00 | 80.00 | 125.00 | 180.00 | 40.00 |
| 5.50 | 88.00 | 137.50 | 198.00 | 44.00 |
| 6.00 | 96.00 | 150.00 | 216.00 | 48.00 |
| 6.50 | 104.00 | 162.50 | 234.00 | 52.00 |
| 7.00 | 112.00 | 175.00 | 252.00 | 56.00 |
| 7.50 | 120.00 | 187.50 | 270.00 | 60.00 |
| 8.00 | 128.00 | 200.00 | 288.00 | 64.00 |
| STANDARD | WERKSTOFF NR. | UNS |
| Nimonic 75 | 2.4951 / 2.4630 | N06075 |
Nimonic 75 Sheets and Plates are primarily made up of 80% nickel and 20% chromium, with small amounts of titanium and carbon added to boost strength and stability. This alloy is known for its excellent resistance to oxidation and scaling at elevated temperatures. In terms of mechanical properties, it boasts a tensile strength of around 760 MPa and a yield strength of about 275 MPa, along with good creep resistance. The material holds its integrity under thermal stress and has a melting point of roughly 1380°C. These characteristics make Nimonic 75 an excellent choice for environments that require strong thermal and mechanical performance.
Contact us to get a quick quote for your requirement.
Nimonic 75 Sheets and Plates find extensive use in industries that need high-temperature strength and oxidation resistance. You’ll commonly see them in applications like gas turbines, jet engine components, exhaust systems, heat exchangers, and parts for industrial furnaces. Their ability to maintain mechanical integrity under extreme conditions also makes them suitable for nuclear engineering and chemical processing facilities. In the aerospace sector, they are frequently used in engine casings and thermal shielding. The alloy’s versatility and durability ensure dependable performance, especially in corrosive and thermally demanding environments, making it a top choice for engineers looking for long-lasting material solutions in critical applications.
