Marsh Nickel Alloy is a leading manufacturer in Canberra, Australia, specializing in quality nickel alloy products. Years of industry experience they offer a range of products, including MP35N sheets and plates, known for their high strength, corrosion resistance and durability These products are widely used in aerospace, marine and medical applications for monitoring find it works well in tight spaces.Marsh Nickel Alloys is committed to providing quality products with exceptional customer service and technical expertise.
Marsh Nickel Alloys, located in Canberra, Australia, is a reputable manufacturer and supplier of high-performance alloys, with a particular focus on MP35N Sheets and Plates. Known for their commitment to top-notch quality and precision-engineered materials, Marsh Nickel Alloys caters to essential industries like aerospace, medical, marine, and chemical processing. Their MP35N Sheets and Plates are designed to meet rigorous international standards, guaranteeing exceptional reliability and performance even in the most extreme conditions. With a strong emphasis on customer satisfaction, innovation, and technical know-how, Marsh Nickel Alloys has established itself as a go-to source for MP35N alloy solutions throughout Australia and beyond.
| Standard Specification : | ASTM F562 / ASME SF562 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Chemical Analysis | |
| Cr | 20 nom |
| Ni | 35 nom |
| Mo | 10 nom |
| Co | 35 nom |
| Material | Condtion | Ultimate Tensile Strength ksi | 0.2 % Yield Strength ksi | Elongation % | Reduction of Area % | Hardness HRC |
| MP35N AMS 5844 | Solution Heat Treated and Work Strengthened | 255 | 225 | 12 | 50 | 45 |
| MP35N AMS 5845 | Solution Heat Treated and Work Strengthened and Aged | 260 | 230 | 8 | 35 | 38 min |
MP35N Sheets and Plates are made from a high-strength, corrosion-resistant nickel-cobalt-chromium-molybdenum alloy. Typically, this alloy consists of around 35% nickel, 35% cobalt, 20% chromium, and 10% molybdenum. This unique blend provides MP35N with remarkable mechanical properties, including tensile strengths that can exceed 200 ksi (1379 MPa) after aging, excellent fatigue resistance, and outstanding resistance to stress corrosion cracking. Even in harsh chemical and marine environments, the alloy maintains impressive strength and ductility. MP35N can also be cold-worked and aged to further boost its mechanical performance, making it ideal for the most demanding structural and biomedical applications.
Contact us to get a quick quote for your requirement.
MP35N Sheets and Plates find extensive use in industries that require high strength, corrosion resistance, and biocompatibility. In aerospace, they are perfect for fasteners, springs, and structural components that face extreme conditions. The medical field appreciates MP35N for its use in surgical instruments and implantable devices, thanks to its biocompatibility and durability. In marine and chemical processing, this alloy stands up to aggressive corrosive environments, making it suitable for pumps, valves, and heat exchangers. Its excellent resistance to stress corrosion cracking and hydrogen embrittlement further solidifies MP35N Sheets and Plates as a preferred material choice.
