Marsh Nickel Alloys is a leading manufacturer and supplier of Inconel sheets and plates based in Canberra, Australia. Our Inconel sheets and plates are engineered for superior performance in extreme environments, offering exceptional resistance to high temperatures, corrosion, and oxidation. Ideal for aerospace, chemical processing, and power generation applications, these products ensure durability and reliability. With a commitment to quality and precision,Marsh Nickel Alloys provides tailored solutions to meet your specific needs, delivering high-performance Inconel sheets and plates that stand up to the most demanding industrial conditions.
| Specifications | : | ASTM B443 / ASME SB443, AMS 5599, AMS 5869 |
|---|---|---|
| Dimensions | : | ASTM, ASME, and API |
| Inconel Sheet | : | thickness range from .008″ to .0125″ |
| Inconel Plate | : | thickness ranges from .0125″ to 5.00″ |
| Size | : | 15NB to 150NB In |
| Tempers | : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness | : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Ni | Al | Fe | Mo | Cr | Cu | P | Nb | C | Mn | S | Si | Co | Ti | B |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 50 – 55 | 0.2 – 0.8 | Bal | 2.8 – 3.3 | 17 – 21 | 0.3 max | 0.015 max | 4.75 – 5.5 | 0.08 max | 0.35 max | 0.015 max | 0.35 max | 1.0 max | 0.65 – 1.15 | 0.006 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | |
| Inconel Sheet and Plates | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 135,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
These Inconel Sheets and Plates are made from a nickel-chromium-based superalloy, renowned for its exceptional resistance to oxidation, pitting, and stress corrosion cracking in both oxidizing and reducing conditions. The material maintains impressive tensile and yield strength, toughness, and fatigue resistance, even when exposed to elevated temperatures. It also resists scaling and keeps its structural integrity during extreme thermal cycling. Each sheet and plate undergoes precision rolling, heat treatment, and thorough testing to ensure they have accurate dimensions, a uniform surface finish, and consistent metallurgical properties, making them suitable for critical industrial applications.
Contact us to get a quick quote for your requirement.
Inconel Sheets and Plates find their way into various industries that require corrosion-resistant and high-performance materials. In aerospace, they are used in jet engine components, exhaust systems, and turbine parts. In the chemical and petrochemical industries, they serve in reactors, heat exchangers, and process equipment that handle corrosive fluids. Power generation facilities utilize them in boilers, gas turbines, and superheater tubes. Their unique blend of strength, durability, and resistance to heat and corrosion makes Inconel Sheets and Plates the go-to choice for extreme service conditions.
