AtMarsh Nickel Alloys, we pride ourselves on being a premier manufacturer and supplier of Inconel forged fittings in Canberra, Australia. With a commitment to exceptional quality and precision, we specialize in providing durable and high-performance forged fittings designed to meet the rigorous demands of various industries. Our products, including Inconel forged fittings, are crafted to offer superior resistance to extreme temperatures and corrosive environments, ensuring reliability and longevity in every application.
Marsh Nickel Alloys, located in Canberra, Australia, stands out as a top-notch manufacturer and supplier of high-quality Inconel Forged Fittings. These fittings are designed to deliver exceptional strength, corrosion resistance, and durability, even in the harshest environments. By employing cutting-edge manufacturing techniques and rigorous quality control measures, the company guarantees that each fitting adheres to international standards, ensuring reliable performance under high temperatures and pressures. Inconel Forged Fittings from Marsh Nickel Alloys are perfect for sectors like oil and gas, chemical processing, marine, and power generation, where components need to endure aggressive media and elevated temperatures.
| Specifications | ASTM B564 & ASME SB564 |
| Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Grades | Inconel 600, 601, 625, 718, 783, 690, X750 Forged Fittings |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Grade | Ni | C | Mn | Si | S | Cu | Fe | Cr |
| Inconel 600 | 72.00 min | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 14.00 – 17.00 |
| Inconel 601 | 58.0 – 63.0 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 21.0 – 25.0 |
| Inconel 625 | 58.0 min | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 20.0 – 23.0 |
| Inconel 718 | 50.00 – 55.00 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
Crafted from a nickel-chromium-based superalloy, Inconel Forged Fittings boast remarkable resistance to oxidation, pitting, and stress corrosion cracking, whether in oxidizing or reducing environments. These fittings are known for their impressive mechanical properties, including high tensile and yield strength, toughness, and fatigue resistance, even at elevated temperatures. The alloy maintains its structural integrity during thermal cycling and exposure to corrosive substances. Each fitting undergoes precision forging, heat treatment, and thorough testing to ensure dimensional accuracy, metallurgical consistency, and leak-proof performance in demanding industrial applications.
Contact us to get a quick quote for your requirement.
Inconel Forged Fittings are extensively utilized in industries that require robust and corrosion-resistant connections. In the oil and gas sector, they find their place in pipelines, valves, and chemical injection systems that come into contact with corrosive fluids. Chemical and petrochemical facilities use them in reactors, heat exchangers, and process equipment that handle harsh chemicals. The marine and offshore industries rely on them for seawater systems and high-pressure environments, while power generation plants incorporate them into turbine and boiler assemblies. With their exceptional blend of mechanical strength, corrosion resistance, and reliability, Inconel Forged Fittings are the go-to choice for critical and high-demand industrial applications.
