Marsh Nickel Alloys is a reputable manufacturer and supplier located in Canberra, Australia, with a focus on high-performance **Inconel 617 Stud Bolts**. These bolts are celebrated for their remarkable strength, resistance to oxidation, and durability even at high temperatures, making them perfect for the toughest environments. Marsh Nickel Alloys prides itself on precision manufacturing, top-notch quality control, and adherence to global standards, ensuring that their products cater to the varied needs of industries like power generation, petrochemical, and aerospace. With Inconel 617 Stud Bolts, you can expect outstanding reliability and longevity, even when faced with extreme thermal and mechanical stress.
Inconel 617 Stud Bolts are made from a nickel-chromium-cobalt-molybdenum alloy, containing about 48–62% nickel, 20–24% chromium, 8–10% cobalt, and 8–10% molybdenum. This unique blend offers excellent resistance to oxidation and carburization at high temperatures. On the mechanical side, they boast high tensile strength (up to 890 MPa), good yield strength, and impressive creep-rupture properties. The alloy remains stable and tough even when exposed to temperatures over 1000°C for extended periods, making it an ideal choice for components that undergo severe thermal cycling and mechanical loading.
Standard ASTM B168, B166 / ASME SB168, SB166
Dimensions ANSI B18.2.1, DIN 931,DIN 933, ISO 4014, ISO 4017,BS 1768, BS1768, IFI 115
Threads Configuration ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads
Type Cold Forged, Hot Forged, Bar Stock Machined, Bar Stock Milling
Size M02 to M160
Length 3 mm to 200 mm
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 617 Stud Bolts in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 617 Stud Bolts find their place in industries that require exceptional heat and corrosion resistance. They’re commonly used in gas turbines, heat exchangers, petrochemical processing plants, and power generation systems. Their outstanding oxidation resistance makes them perfect for furnace hardware and high-temperature ducting. In the aerospace industry, you’ll find them in combustion chambers and turbine components. Plus, Inconel 617 Stud Bolts are reliable in chemical processing environments that involve both oxidizing and reducing agents, ensuring a long service life and structural integrity in critical applications.
