Marsh Nickel Alloys is a reputable manufacturer and supplier located in Canberra, Australia, specializing in high-performance **Inconel 601 Stud Bolts**. Known for their remarkable strength and resistance to oxidation, these stud bolts are perfect for high-temperature and corrosive settings. Marsh Nickel Alloys guarantees precise engineering, a superior finish, and compliance with international quality standards. With a strong emphasis on reliability and performance, the company offers Inconel 601 Stud Bolts that are well-suited for demanding industrial applications, ensuring a long service life, consistent performance, and resistance to scaling even in extreme heat conditions across various industries in Australia and beyond.
Inconel 601 Stud Bolts are primarily made up of nickel (58–63%), chromium (21–25%), and iron, with trace amounts of aluminum, carbon, and silicon that enhance their oxidation resistance. This alloy boasts impressive mechanical strength, featuring a tensile strength of around 650 MPa and a yield strength of about 300 MPa. It maintains its toughness and hardness even at high temperatures, offering excellent resistance to carburization and oxidation. These characteristics make Inconel 601 Stud Bolts incredibly durable and perfect for harsh operating environments.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Stud Bolts in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 601 Stud Bolts are widely utilized in high-temperature and corrosive environments thanks to their outstanding strength and oxidation resistance. They find common use in heat treatment equipment, furnace components, gas turbine exhaust systems, petrochemical processing, and power generation plants. Additionally, they are extensively employed in the chemical processing, aerospace, and marine engineering sectors, where exposure to high heat and corrosive atmospheres is prevalent. Their exceptional mechanical stability and resistance to scaling make them ideal for securing components in applications that involve thermal cycling and prolonged exposure to extreme conditions.
