Marsh Nickel Alloys is a leading manufacturer and supplier of Inconel 601 sheets and plates based in Canberra, Australia. Our Inconel 601 products are designed to excel in extreme temperatures, offering superior resistance to oxidation and carburization. Ideal for high-temperature applications such as furnace components, heat exchangers, and chemical processing equipment, these sheets and plates ensure exceptional durability and performance. With a focus on quality and precision,Marsh Nickel Alloys delivers tailored solutions to meet your specific needs, providing reliable and long-lasting Inconel 601 sheets and plates for demanding industrial environments.
| 601 Sheets & Plates Specifications | ASTM B168 / ASME SB168, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| 601 Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Alloy 601 Sheets & Plates Size Range | Cold rolled ASME SB168 Grade 601 Inconel Sheet 0.5-6.4 mm Hot rolled ASME SB168 Grade 601 Inconel Sheet 3.0–10.0 mm |
| 601 Inconel Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Inconel 601 Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Inconel 601 Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Inconel 601 Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Inconel 601 Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SB168 601 Inconel Strips EN 10088 SA -240-601 Strips |
| Finish of Inconel 601 Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
| Inconel 601 Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.00 max | 0.50 max | 0.015max | 1.00 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
**Inconel 601 Sheets and Plates** are primarily made from nickel, chromium, and aluminum, which give them remarkable resistance to oxidation, scaling, and carburization at high temperatures. This material boasts impressive mechanical properties, such as high tensile and yield strength, toughness, and fatigue resistance. It maintains its structural integrity even under repeated heating and cooling cycles and stands up to both acidic and alkaline conditions. Each sheet and plate is carefully rolled, heat-treated, and thoroughly tested to ensure precise dimensions, metallurgical consistency, and a smooth surface finish that’s perfect for critical applications.
Contact us to get a quick quote for your requirement.
**Applications of Inconel 601 Sheets and Plates** range from furnace components and heat exchangers to gas turbine parts and chemical process equipment. In the power generation sector, they are utilized for boiler and superheater components that face high temperatures. The aerospace industry uses them for engine parts and exhaust systems that require superior oxidation and corrosion resistance. In the chemical and petrochemical fields, they are essential for reactors, piping systems, and process vessels that handle aggressive chemicals. With their exceptional heat resistance, mechanical strength, and corrosion protection, Inconel 601 Sheets and Plates are the go-to choice for demanding industrial applications.
