Marsh Nickel Alloys, based in Canberra, Australia, stands out as a top-notch manufacturer and supplier of high-quality Incoloy valves. By utilizing cutting-edge manufacturing techniques and maintaining rigorous quality controls, the company crafts valves that deliver outstanding strength, corrosion resistance, and reliability in tough environments. Marsh Nickel Alloys caters to various industries, including aerospace, power generation, chemical processing, and oil and gas, providing Incoloy valves designed to excel under extreme temperatures and harsh chemical conditions.
Incoloy valves are primarily composed of nickel, iron, and chromium alloys, with additional elements like molybdenum, copper, and titanium incorporated to boost corrosion resistance and mechanical strength. This unique blend ensures remarkable resistance to oxidation, carburization, and corrosion, even at high temperatures. On the mechanical side, Incoloy valves showcase impressive tensile strength, toughness, and durability, ensuring tight seals and operational integrity, even when faced with intense thermal and mechanical pressures.
| Material | Incoloy |
|---|---|
| Seal Material | PTFE/ RPTFE |
| Working Pressure | 1.6 – 6.4Mpa |
| Working Temperature | -29°C — +180°C |
| Availabe Size | 1/2″-4″,(DN15-DN100) |
| Available Connection | BSP/ BSPT/ NPT/ Flanged/ Welded |
| Nominal Pressure | P10/PN16 |
| Operation | Manual,Pneumatic, Electric |
| Suitable Medium | Water,Sewage,Seawater,Gas,Food,Oils,etc |
| Standards | GB9112,DIN2501,BS4504,ISO2084,ANSI125 |
| Applications | Water, Oil, Gas, |
| Nominal Diameter | DN40-DN300 handle lever DN350-DN1200 gear box |
| Operation Temperature | -10°C~150°C |
| Grade | Ni | Fe | Cr | Cu | Mn | S | Si | Ti | Al | C |
| Alloy 800 | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .15-.60 | .15-.60 | .1 max |
| Alloy 800HT | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .25-.60 | .85-1.20 | .06-.10 max |
| Alloy 800H | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .15-.60 | .15-.60 | .05-.10 max |
| Density | Yield Strength (0.2%Offset) | Melting Point | Tensile Strength | Elongation |
| 7.94 g/cm3 | Psi – 30,000 , MPa – 205 | 1350-1400 ℃ | Psi – 75,000 , MPa -520 | 30 – 35 % |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy Valve in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy valves find extensive use in power generation plants, where they manage steam and gas flows in boilers and turbines. The chemical processing sector depends on these valves for pipelines and reactors that deal with corrosive fluids. In aerospace, they are crucial for fuel and hydraulic systems that endure extreme heat. Moreover, the oil and gas industry relies on Incoloy valves in offshore platforms, refineries, and subsea operations, where strength, corrosion resistance, and leak-tight performance are absolutely essential.
