Marsh Nickel Alloys, located in Canberra, Australia, stands out as a top manufacturer and supplier of Incoloy 800/800H/800HT flanges in Dubai, UAE. Known for their precision engineering and high-quality products, the company specializes in flanges that excel in high-temperature and corrosive environments. With state-of-the-art manufacturing facilities and a talented workforce, Marsh Nickel Alloys guarantees that their products meet global standards, providing durability, precise dimensions, and outstanding mechanical strength. Industries around the world rely on their Incoloy flanges for dependable performance in petrochemical, power generation, and process plant applications where strength and resistance to oxidation are essential.
Specifications : ASTM B 564 / ASME SB 564
Dimensions : ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
Standards : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges etc.
Size : 1/2″ to 36″
Pressure Rating : Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500 | PN6, PN10, PN16, PN25, PN40, PN64 etc.
Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
| C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti | |
| Incoloy | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | |
| Incoloy Flanges | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 800/800H/800HT Flanges in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 800/800H/800HT flanges find extensive use in applications that demand exceptional strength and oxidation resistance at high temperatures. They are commonly found in heat exchangers, pressure vessels, boilers, petrochemical processing units, and power generation plants. Additionally, these flanges are well-suited for furnace components, heat-treating equipment, and chemical processing systems where stability and corrosion resistance are vital. In sectors like oil and gas, refineries, and nuclear power, Incoloy 800 series flanges provide long-lasting reliability and safe operation in challenging, high-temperature, and high-pressure environments.
