Home > Haynes 25 / L605 Foil
Marsh Nickel Alloys is a leading manufacturer and supplier based in Canberra, Australia, specializing in high-quality metal alloys, including Haynes 25 (L605) foil. Known for its excellent strength, corrosion resistance, and high-temperature performance, Haynes 25 is widely used in aerospace, chemical, and industrial applications. With a commitment to delivering premium products,Marsh Nickel Alloys ensures timely supply of precision-engineered materials, providing customized solutions to meet the diverse needs of clients across various industries.
| Standard Specification : | AMS 5759, AMS 5537 |
| Dimensions : | AMS, AMS, API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat T |
| Grade | C% | Si≤ % | Mn≤ % | P≤ % | S≤ % | Cr% | Ni% | Co% | Fe % | W % |
| Haynes 25 / L605 | 0.05-0.15 | 0.40 | 2.00 | 0.02 | 0.015 | 19.0-21.0 | 9.00-11.0 | Rest | ≤ 3.00 | 14.0-16.0 |
| Grade | 0.2% Yield strength Rp ≥ N/mm² | Tensile strength Rm N/mm² | Elongation A5 | Resistant on air up to°C | Modulus of elasticity kN/mm² |
| Haynes 25 / L605 | 345 | 830-1130 | 25 | 1090 | 225 |
The Haynes 25 (L605) foil crafted by Marsh Nickel Alloys features a unique blend of high-nickel, cobalt-chromium alloy, enhanced with molybdenum and iron. This special formulation delivers remarkable resistance to oxidation, carburization, and high-temperature corrosion. The foil boasts impressive mechanical properties, including high tensile strength and creep resistance, making it perfect for applications that demand durability in extreme thermal and chemical conditions.
Contact us to get a quick quote for your requirement.
In Canberra, Haynes 25 foil from Marsh Nickel Alloys finds extensive use in the aerospace, power generation, chemical processing, and petrochemical sectors. Its exceptional heat and corrosion resistance make it ideal for turbine blades, heat shields, gas turbine components, and other critical parts that face harsh environments. Marsh Nickel Alloys is committed to ensuring that their Haynes 25 (L605) foil offers long-lasting performance and reliability in the most demanding industrial applications.
