Marsh Nickel Alloys, located in Canberra, Australia, stands out as a top manufacturer and supplier of high-quality Haynes 230 bars. With cutting-edge production methods and strict quality controls, the company produces bars that boast remarkable strength, resistance to oxidation, and long-lasting durability. They cater to various industries, including aerospace, power generation, chemical processing, and oil and gas, offering Haynes 230 bars that are specifically designed to excel in extreme heat and corrosive conditions.
The composition of Haynes 230 bars mainly includes nickel, chromium, tungsten, and molybdenum, along with trace amounts of iron, manganese, and silicon to boost their mechanical and thermal characteristics. This unique alloy mix ensures excellent resistance to oxidation, nitridation, and carburization, even at high temperatures. On the mechanical side, Haynes 230 bars showcase impressive tensile and creep strength, outstanding ductility, and stability during prolonged thermal exposure, making them perfect for high-temperature applications.
| Standards : | ASTM 5878, ASME S5878 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Grade | C | Mn | P | S | Si | Ni | Cr | Fe | W | B | La | Co | Ai | Ti | Cu | La | Mo |
| Haynes 230 | 0.05-0.15 | 0.30-1.0 | 0.03 max | 0.015 max | 0.25-0.75 | Rem | 20.0-24.0 | 3.0 max | 13.0-15.0 | 0.015 max | 0.005-0.05 | 5.0 max | 0.20-0.50 | 0.10 max | 0.50 max | 0.005-0.05 | 1.0-3.0 |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Hardness HB |
| ksi – 758, MPa – 110 | ksi – 310, MPa – 45 | 35 % | 241 max |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Haynes 230 Bar in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
In the aerospace sector, Haynes 230 bars are commonly used for gas turbine components, combustors, and afterburners. The power generation industry relies on these bars for boilers, heat exchangers, and industrial furnaces that operate at elevated temperatures. Chemical processing facilities depend on Haynes 230 bars for reactors and equipment that come into contact with oxidizing and corrosive gases. Moreover, the oil and gas industry utilizes these bars in refining systems and offshore platforms, where exceptional oxidation resistance and mechanical strength are crucial.
