Marsh Nickel Alloys stands out as a leading manufacturer and supplier of Hastelloy Ball Valves, proudly based in Canberra, Australia. The company has built a solid reputation for providing top-notch nickel-based alloy products, focusing on components that can withstand extreme chemical and high-temperature conditions. Their Hastelloy Ball Valves are renowned for exceptional corrosion resistance, durability, and dependable performance, making them perfect for critical industrial applications. With a commitment to advanced engineering, precision manufacturing, and rigorous quality control, each valve is meticulously crafted to meet international standards, ensuring they operate efficiently for the long haul. These valves are a trusted choice in the chemical processing, petrochemical, marine, and power generation sectors, thanks to their outstanding reliability and performance.
Hastelloy Ball Valves are primarily made from nickel, molybdenum, and chromium, with small amounts of iron, tungsten, and cobalt varying by grade. This unique blend gives them remarkable mechanical properties, such as high tensile and yield strength, excellent toughness, and impressive resistance to corrosion, pitting, and stress cracking. They maintain their structural integrity even under high pressure and temperature, ensuring smooth operation and a long service life, even in harsh chemical and marine environments. Their combination of strength and corrosion resistance guarantees reliable sealing and performance, even in the toughest conditions.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | C | Co | S | Si | Cr | Ni | Mo | Fe | W |
| Alloy C22 | 0.50 max | 0.010 max | 2.5 max | 0.02 max | 0.08 max | 20 – 22.5 | Bal | 12.5 – 14.5 | 2 – 6 | 2.5 – 3.5 |
| Alloy C276 | 1.0 max | 0.010 max | 2.5 max | 0.03 max | 0.08 max | 14.5 – 16.5 | Bal | 15 – 17 | 4 – 7 | 3 – 4.5 |
| Element | Melting Point | Yield Strength (0.2%Offset) | Density | Tensile Strength | Elongation |
| Alloy C22 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | 8.69 g/cm3 | Psi – 1,00,000 , MPa – 690 | 45 % |
| Alloy C276 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | 8.89 g/cm3 | Psi – 1,15,000 , MPa – 790 | 40 % |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Ball Valve in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
These Hastelloy Ball Valves find extensive use in industries that demand high-performance, corrosion-resistant flow control solutions. In the chemical and petrochemical fields, they expertly manage the flow of aggressive acids, chlorides, and other corrosive substances. The marine and offshore sectors utilize them in seawater systems, desalination plants, and offshore platforms. Moreover, they play a crucial role in pharmaceutical, power generation, and oil and gas applications, where precision, durability, and reliability are paramount. Hastelloy Ball Valves are the go-to choice for controlling fluids in high-temperature, high-pressure environments.
