Marsh Nickel Alloys, located in Canberra, Australia, stands out as a top manufacturer and supplier of high-quality Duplex Steel flanges. By leveraging cutting-edge production technology and adhering to strict quality standards, the company creates flanges that boast exceptional strength, corrosion resistance, and durability. Marsh Nickel Alloys serves a variety of industries, including chemical processing, oil and gas, power generation, and marine engineering, providing Duplex Steel flanges that are built to perform reliably even in tough and corrosive conditions.
| Specifications | ASTM A182 / ASME SA182 |
| Size | 1/8″ NB TO 48″ NB |
| Standards | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
| Grades | S31803 / S32205 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61 |
| Grade | Duplex Steel Flanges |
|---|---|
| C | 0.030 max |
| Mn | 2.00 max |
| Si | 1.00 max |
| P | 0.030 max |
| S | 0.020 max |
| Cr | 22.0 – 23.0 |
| Mo | 3.0 – 3.5 |
| Ni | 4.50 – 6.50 |
| N | 0.14 – 0.20 |
| Fe | 63.72 min |
| Duplex Steel | Flanges |
|---|---|
| Density (g/cm 3) | 7.805 |
| Density (lb/in 3) | 0.285 |
| Melting Point (°C) | 1420 – 1465 |
| Melting Point (°F) | 2588 – 2669 |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Steel Flanges in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
In industries like oil and gas, Duplex Steel flanges are commonly used to connect pipelines, valves, and pumps in both offshore and onshore facilities. Chemical processing plants rely on them for reactors, heat exchangers, and pressure vessels that come into contact with aggressive chemicals. Power generation facilities utilize Duplex Steel flanges in boilers, condensers, and turbine systems. Moreover, they find applications in marine and desalination plants, where their exceptional corrosion resistance and mechanical performance guarantee a long service life and safe operations.
