Marsh Nickel Alloys, based in Canberra, Australia, is a reputable manufacturer and supplier of top-notch Duplex Steel bars. With a commitment to advanced manufacturing techniques and rigorous quality control, the company produces bars celebrated for their remarkable strength, resistance to corrosion, and long-lasting durability. They cater to various industries, including chemical processing, oil and gas, power generation, and marine engineering, delivering Duplex Steel bars that are designed to perform reliably even in the toughest environments.
| Duplex Steel Bar Standard | ASTM A276, AMS 5513, AMS 5511, AMS 5647 |
|---|---|
| Duplex Steel Bar Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Duplex Steel Round bar size | Diameter: 3-~800mm |
| Duplex Steel Hex Bar size | 2-100mm A/F |
| Duplex Stainless Steel Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Duplex Steel Square bar size | 4 to 100mm |
| Duplex Steel Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Duplex Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Duplex Steel Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| ASTM A276 Type Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Duplex Stainless Steel Threaded Bar Billet Size | 1/2 to 495mm Diameter |
| Duplex Steel Rectangular Size | 33 x 30mm to 295 x 1066mm |
| Duplex Hex Bars Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| ASTM A276 Type Hollow Bar Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| SAF 2507 T-Bar Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Rolled Duplex Steel Flat Bars Condition | Hardened & tempered, annealed |
| ASTM A276 Type Cold Rolled Bar Technique | Duplex Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Duplex Rod Processing | Bar cutting to 650mm |
| Duplex Rounds Bar Form | Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Grade | UNS No | C % | Cr % | Ni % | P % | Si % | S % | Mo % | N % | Mn % |
| S31803 | S31803 | < 0.03 | 21.0-23.0 | 4.5-6.5 | 1.03 max | 1 max | 0.02 max | 2.5-3.5 | 0.08-0.2 | < 2.0 |
| 2205 | S32205 | < 0.03 | 22.0-23.0 | 4.5-6.5 | 0.03 max | 1 max | 0.02 max | 3.0-3.5 | 0.14-0.20 | < 2.0 |
| Grade | YS (MPa) | UTS (MPa) | % Elongation | Hardness(BHN) |
| S31803 | 450 min. | 620 min. | 25 min. | 293 max. |
| 2205 | 450 min. | 655 min. | 25 min. | 293 max. |
Duplex Steel bars boast a well-balanced microstructure that combines austenitic and ferritic stainless steel, enriched with high levels of chromium, nickel, molybdenum, and nitrogen. This distinctive blend provides exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking. On the mechanical side, Duplex Steel bars are known for their high tensile strength, impressive toughness, and outstanding fatigue resistance, ensuring they maintain their structural integrity even under extreme pressure and temperature fluctuations.
Contact us to get a quick quote for your requirement.
These Duplex Steel bars are commonly utilized in chemical processing plants for creating pressure vessels, heat exchangers, and piping components that come into contact with harsh chemicals. In power generation facilities, they are used in turbine shafts, boiler components, and condensers. The oil and gas sector relies on Duplex Steel bars for offshore platforms and subsea equipment, while the marine industry incorporates them in shipbuilding and desalination plants, thanks to their exceptional corrosion resistance and mechanical performance.
