Home > Duplex Steel > Duplex Steel 2205 Forged Fittings
Marsh Nickel Alloys is a top-notch manufacturer and supplier located in Canberra, Australia, with a focus on high-quality Duplex Steel 2205 Forged Fittings. These fittings are celebrated for their exceptional strength, toughness, and resistance to corrosion, making them perfect for even the toughest industrial settings. At Marsh Nickel Alloys, there’s a strong commitment to precision manufacturing and rigorous quality control, ensuring that every product is consistent and reliable. Duplex Steel 2205 Forged Fittings find their place in various industries, including oil and gas, chemical processing, marine, and power generation, delivering robust and long-lasting solutions for piping systems and critical infrastructure that face high pressures, corrosive substances, and harsh operational conditions.
| 2205 Duplex Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
|---|---|
| Duplex 2205 Pipe Fittings size | Seamless 2205 Duplex Stainless Butt Weld Fittings: 1/2″ – 10″ Welded 2205 Stainless Steel Butt Weld Fittings: 1/2″ – 48″ |
| Specifications | ASTM A815 / ASME SA815 |
| Duplex 2205 Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Duplex 2205 Forged Fittings Thread | NPT, BSPT, BSPP |
| ASTM A815 Fittings Type | DN15-DN1200 |
| 2205 Duplex Pipe Fittings Types | Seamless / ERW / Welded / Fabricated Duplex 2205 Werkstoff 1.4462 Pipe Fittings |
| Fitting Duplex 2205 Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom Avesta 2205 Pipe Fittings |
| Duplex 2205 Forged Fittings Pressure Rating | Threaded end-2000lb/ 3000lb/ 6000lbs 2205 Duplex 1.4462 Pipe Fittings Socket-weld end-3000/ 6000/ 9000lbs 2205 Duplex Stainless Steel Pipe Fittings |
| Fitting Duplex 2205 Size Range | 1/2″ NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) |
| Duplex 2205 F51 Pipe Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| Key markets and industries for 22cr Fitting Duplex 2205 |
|
| Duplex 2205 Elbow | Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D. Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Crosses, Equal Tees & Reducing Tees,Couplings, Reducers, Inserts, Unions, Caps, Nipples, Forged Pipe Fittings, Socket Weld & Threaded, 90° & 45° Elbows – Female-Female, Male-Male, Male-Female, Union, Nipples, Couplings, Plugs Fittings |
| 2205 Duplex Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| SA815 Material End |
|
| F51 2205 Duplex Pipe Fittings uses & application |
|
| 2205 Duplex Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian (NO CHINA) |
| Material Test Certificates (MTC) for Duplex 2205 Fittings as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
|---|---|---|---|---|---|---|---|---|---|
| 1.0 | 0.03 | 0.02 | 2.0 | 3.0 – 3.5 | 22.0 – 23.0 | 0.03 | 4.5 – 6.5 | 0.14 – 0.2 | Bal |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
|---|---|---|---|---|
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Steel 2205 Forged Fittings in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex Steel 2205 Forged Fittings are commonly found in oil and gas pipelines, chemical and petrochemical plants, desalination systems, and marine engineering projects. They’re perfect for connecting valves, pumps, flanges, and other essential piping components in corrosive and high-pressure settings. With excellent resistance to pitting, crevice corrosion, and stress corrosion cracking, these fittings guarantee leak-free, durable joints. Their remarkable strength, corrosion resistance, and long-term reliability make them indispensable for offshore platforms, refineries, chemical reactors, and heat exchangers that operate under challenging conditions.
