Marsh Nickel Alloys, located in Canberra, Australia, is a reputable manufacturer and supplier of top-notch Copper Nickel wire. With cutting-edge manufacturing techniques and strict quality control, the company produces wire that boasts impressive corrosion resistance, electrical conductivity, and mechanical strength. Marsh Nickel Alloys caters to various industries, including marine, chemical processing, electronics, and power generation, offering Copper Nickel wire that’s built to perform reliably even in the toughest conditions.
Copper Nickel wire is generally made from an alloy containing 10% to 30% nickel mixed with copper, which significantly boosts its resistance to seawater corrosion and biofouling. This alloy showcases remarkable mechanical properties, such as good tensile strength, ductility, and flexibility, making it perfect for wiring applications. Plus, Copper Nickel wire remains stable across a broad temperature range and provides excellent electrical conductivity.
| Specifications | ASTM B206, ASME SB206 | |
|---|---|---|
| Copper Nickel Wire Grades | 90/10 Copper Nickel Wire, 70/30 Copper Nickel Wire (Cuni 90/10 & Cuni 70/30) | |
| Copper Nickel Wire Dimensions | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 | |
| Copper Nickel Wire Length | 100 mm TO 6000 mm, customizable | |
| Copper Nickel Wire Diameter | 10 mm To 100 mm or as per client requirement | |
| Copper Nickel Wire Main Types |
| |
| Copper Nickel Wire Density | 8.89 g/cm3 | |
| 580-750 | |
| as standard | |
| 28-30 | |
| Surface | Polished bright, Smooth | |
| Copper Nickel Wire Technique | Cold Rolled, hot rolled | |
| Copper Nickel Wire Condition | M, Y, 1/2Hard | |
| Tempers | Tempers range from dead soft annealed to ultra spring temper | |
| Copper Nickel welded wire mesh | Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch Roll Length: 100feet or 150feet | |
| Copper Nickel wire mesh weaving methods | plain weave, twill weave, dutch weave | |
| Offered in a wide range of packages including: |
|
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu-Ni 70-30 | 65.0 min | 1 max | .05 max | 29-33 | 0.4-1.0 | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.89 g/cm3 | 2260 F | 50000 psi | 20000 psi | 30 % |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel Wire in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
In marine settings, Copper Nickel wire is a go-to choice for shipbuilding, desalination plants, and offshore platforms, thanks to its impressive resistance to seawater corrosion. It’s also utilized in chemical plants for wiring and electrical components that face corrosive environments. In the electronics sector, Copper Nickel wire acts as a dependable conductor in specialized equipment, while power generation facilities rely on it for wiring in generators and transformers, where durability and corrosion resistance are essential.
