Home > Copper Nickel > Copper Nickel 90/10 Sheet and Plates
Marsh Nickel Alloys, located in Canberra, Australia, has built a solid reputation as a reliable manufacturer and supplier of top-notch Copper Nickel 90/10 Sheets and Plates. With a strong focus on precision engineering and strict quality control, they deliver products that boast outstanding corrosion resistance, strength, and durability. These Copper Nickel 90/10 Sheets and Plates are expertly crafted to perform consistently in challenging marine, offshore, and industrial settings where they face seawater, brine, and other corrosive substances. The company guarantees that every product adheres to international standards, providing long-lasting and trustworthy solutions for critical applications in demanding industries.
Made up of roughly 90% copper and 10% nickel, with a touch of iron and manganese for added strength and toughness, Copper Nickel 90/10 Sheets and Plates showcase impressive mechanical properties. They have a tensile strength ranging from about 275 to 350 MPa, along with high ductility and toughness. This alloy also excels in resisting stress corrosion, biofouling, and erosion in seawater and other harsh environments. Plus, with excellent thermal and electrical conductivity, these sheets and plates ensure reliable performance and stability even under tough operating conditions.
Dimensions : ASTM, ASME and API
Standard :ASTM / ASME SB 171, SB 151
Size : 1 mm to 100 mm
Form : Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Finish : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Length : Single Random, Double Random & Cut Length
| Grade | Cu | Mn | Pb | Fe | Zn | Ni |
| Cupro Nickel 90/10 | 88.6 min | 1.0 max | .05 max | 1.8 max | 1 max | 9-11 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Cu-Ni 90/10 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 90/10 Sheet and Plates in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel 90/10 Sheets and Plates find their place in various industries that demand durable, corrosion-resistant materials. They’re commonly used in shipbuilding, offshore oil and gas platforms, desalination plants, heat exchangers, and seawater piping systems. Additionally, you’ll find them in condensers, power generation units, and chemical processing equipment that come into contact with seawater or other corrosive fluids. Their unique blend of strength, corrosion resistance, and durability makes them perfect for structural components and industrial applications. Marsh Nickel Alloys offers Copper Nickel 90/10 Sheets and Plates in a range of sizes and thicknesses, ensuring consistent quality, performance, and longevity.
