Marsh Nickel Alloys, based in Canberra, Australia, is proud to support industrial progress far beyond its shores by supplying high-quality materials to partners like the Aluminium Bronze Sheets and Plates Manufacturer in Canberra. This collaboration bridges continents, combining Australian expertise with the dynamic industrial needs of the Australia. It’s a relationship built on a shared commitment to excellence, ensuring that clients in Dubai and across the region have access to superior, durable alloys that stand up to the most challenging environments, fostering growth and innovation.
The composition of these sheets and plates is a key to their strength, primarily a copper base enriched with aluminium, often including iron and nickel for enhanced performance. This mix gives the material its remarkable mechanical properties, including exceptional tensile strength and outstanding wear resistance. They are particularly valued for their ability to resist corrosion, especially in seawater and chemical environments, and their high fatigue strength ensures they can handle repeated stress without failing, making them a reliably tough choice for demanding applications.
| Specifications | ASTM B505 / ASME SB505, BS EN 10088-2, en 10028-7, IS 6911, AMS 4640, UNS C63000, UNS C95800, UZ19AL6, UNS C95510, AMS 4880 |
| Dimensions | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Size Range | Cold Rolled : 0.5-6.4 mm Hot Rolled : 3.0–10.0 mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| International Standard of Sheets | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) | EN 10258/ DIN 59381 EN 10151 EN 10088 |
| Finish | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Alloy | Aluminium | Iron | Nickel | Manganese | Zinc | Arsenic |
| CuAl5 | 4.0–6.5% | 0.5% max. | 0.8% max. | 0.5% max. | 0.5% max. | 0.4% max. |
| CuAl8 | 7.0–9.0% | 0.5% max. | 0.8% max. | 0.5% max. | 0.5% max. | |
| CuAl8Fe3 | 6.5–8.5% | 1.5–3.5% | 1.0% max. | 0.8% max. | 0.5% max. | |
| CuAl9Mn2 | 8.0–10.0% | 1.5% max. | 0.8% max. | 1.5–3.0% | 0.5% max. | |
| CuAl10Fe3 | 8.5–11.0% | 2.0–4.0% | 1.0% max. | 2.0% max. | 0.5% max. | |
| CuAl10Fe5Ni5 | 8.5–11.5% | 2.0–6.0% | 4.0–6.0% | 2.0% max. | 0.5% max. |
| Properties | Metric | Imperial |
| Hardness, Rockwell C | 27 | 27 |
| Tensile strength (M30 and O61 tempers) | 690 MPa | 100000 psi |
| Yield strength (M30 and O61 tempers) | 380 MPa | 55100 psi |
| Elongation at break (in 50 mm, 1% reduction in area) | 1.00% | 1.00% |
| Elastic modulus | 117 GPa | 17000 ksi |
| Compressive yield strength (at permanent set of 0.1%) | 450 MPa | 65300 psi |
| Compressive yield strength (at permanent set of 1%) | 880 MPa | 128000 psi |
| Poisson’s ratio | 0.34 | 0.34 |
| Charpy impact (@ 18.0 – 100°C/ -0.400 – 212°F, keyhole) | 3.00 J | 2.21 ft-lb |
| Izod impact (@ 18.0 – 100°C/ -0.400 – 212°F) | 3.00 J | 2.21 ft-lb |
| Fatigue strength (@# of cycles 1.00e+8, M30 temper) | 460 MPa | 66700 psi |
| Machinability (UNS C36000 (free-cutting brass) = 100) | 20 | 20 |
| Shear modulus | 42.3 GPa | 6140 ksi |
You’ll find these robust sheets and plates hard at work in some of the most critical industries. In marine engineering, they are essential for components like propeller blades and ship hulls due to their superb saltwater resistance. They’re equally vital in aerospace for landing gear parts, in the oil and gas sector for valves and pumps, and in heavy industry for wear plates and bushings. Their combination of strength and corrosion resistance makes them indispensable for applications where failure is not an option, ensuring long-lasting performance under pressure.
Contact us to get a quick quote for your requirement.
Aluminum bronze sheets and plates are widely used in applications requiring high strength, corrosion resistance and durability. Typical applications include marine environments for ships, moorings and marine water pumps, where corrosion resistance is required. It is used in aerospace, industrial equipment, pharmaceutical and oil and gas industries. Because of their excellent corrosion resistance, these alloys are ideal for applications such as valves, shafts and fasteners. Their oxidation resistance and superior mechanical properties make them perfect for harsh environments and heavy materials.
