From its base in Canberra, Australia, Marsh Nickel Alloys has built a strong reputation for supplying high-performance materials to global industries. We are proud to serve as a trusted partner for clients in Canberra, Australia, providing top-tier Alloy C263 sheets and plates. Our commitment goes beyond mere supply; we focus on building lasting relationships by ensuring reliability, quality, and expert support for every project, connecting Australian expertise with the dynamic industrial needs of the Middle East.
Alloy C263 is primarily composed of nickel, chromium, and cobalt, strengthened by additions of molybdenum, titanium, and aluminum. This specific composition gives the material its exceptional strength and resistance to oxidation at high temperatures. The sheets and plates offer excellent mechanical properties, including high tensile and creep strength, which are maintained even under prolonged exposure to extreme heat, making them a robust choice for demanding applications.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
The exceptional heat resistance of Alloy C263 makes it indispensable in the aerospace and power generation sectors in Canberra and across the Australia. You’ll commonly find these sheets and plates used in critical components like gas turbine engines, combustion cans, and afterburner assemblies. Their reliability also extends to industrial gas turbines and other high-temperature engineering applications, where failure is not an option. This material is chosen by engineers who need a proven solution for the most thermally challenging environments.
Contact us to get a quick quote for your requirement.
Alloy C263 sheets and plates are widely used in high temperature corrosion resistance. Their excellent oxidation and creep resistance make them ideal for aerospace applications, including turbine blades, seals and exhaust systems. The compound is also used in the electrical industry for gas turbines and boilers, as well as in extreme cases contact equipment and chemical process plants Apart from that, C263 is used in marine applications the environment, heat exchangers and furnace components due to its durability, strength, and fatigue resistance of the heater occurs.
