Marsh Nickel Alloys stands out as a top-notch manufacturer and supplier of Alloy C263 Foil, proudly based in Canberra, Australia. The company has earned a stellar reputation for its dedication to precision engineering and high-quality materials, delivering high-performance nickel-based alloys that cater to critical industrial needs. Among its premium offerings, Alloy C263 Foil shines for its remarkable strength, resistance to oxidation, and durability even in the harshest environments. Thanks to its cutting-edge manufacturing capabilities and rigorous quality control measures, Marsh Nickel Alloys guarantees that every piece of Alloy C263 Foil meets the stringent demands of industries like aerospace, chemical processing, and power generation around the globe.
Alloy C263 Foil is a unique blend of nickel, cobalt, chromium, and molybdenum, enhanced with age-hardening elements like titanium and aluminum. Its typical makeup features nickel (the balance), cobalt (20%), chromium (20%), molybdenum (6%), titanium (2.1%), and aluminum (0.3%). This alloy boasts impressive tensile and yield strength, outstanding creep resistance, and exceptional oxidation resistance at temperatures reaching up to 800°C (1472°F). It strikes a perfect balance between high ductility and good formability, making it an excellent choice for high-temperature settings where both strength and corrosion resistance are vital.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Alloy C263 Foil in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Industries that require top-tier strength and oxidation resistance at elevated temperatures widely utilize Alloy C263 Foil. In the aerospace sector, it’s commonly found in turbine engine components, combustion liners, and exhaust systems. The chemical and petrochemical industries rely on it for reactors, heat exchangers, and gas processing equipment due to its impressive corrosion resistance. Moreover, Alloy C263 Foil plays a crucial role in power generation, automotive exhaust systems, and industrial gas turbines, where thermal stability and mechanical integrity are paramount. Its blend of strength, durability, and workability ensures it performs reliably in even the most challenging operating conditions.
