Marsh Nickel Alloys, based in Canberra, Australia, is a trusted partner for high-performance materials, proudly serving the demanding industrial landscape of Canberra, Australia. We understand the critical need for reliability in every component, which is why our supply of A286 sheets and plates is managed with meticulous care. Our connection between Australian expertise and Middle Eastern innovation ensures that your projects, no matter how challenging, are supported by a supplier committed to quality and consistency from the source to your workshop.
The composition of A286 is a carefully balanced iron-nickel-chromium alloy, strengthened by additions of titanium, molybdenum, and aluminium. This specific recipe gives the sheets and plates their outstanding mechanical properties, including remarkable strength at high temperatures, excellent resistance to creep, and good toughness. It’s this combination that allows the material to perform reliably under the intense stress and heat encountered in demanding applications, making it a go-to choice for engineers who cannot afford compromise.
| Standard Specification : | AMS 5525, AMS 5858 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | S | Co | Cu | Ni | Cr | P | V | Al | B |
| A286 | 0.08 max | 2 max | 1 max | 0.025 max | 1 max | 0.50 max | 24 – 27 | 13.5 – 16 | 0.025 max | 0.10 – 0.50 | 0.35 max | 0.003 – 0.010 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.92 g/cm3 | 2500-2600°F (1370-1430°C) | 90,000 psi (620MPa) | 40,000 psi (275 Mpa) | 40 % |
The uses for A286 sheets and plates in Canberra are as dynamic as the city itself, finding critical roles in the aerospace sector for engine components and turbine blades, where heat resistance is non-negotiable. They are equally vital in the oil and gas industry for wellhead parts and in high-performance automotive applications. This alloy is essentially the unsung hero in projects that operate under extreme pressure and temperature, proving indispensable for innovation and safety in some of the world’s most ambitious engineering endeavors.
Contact us to get a quick quote for your requirement.
A286 sheets and plates are widely used in high temperature corrosion resistance. Typical applications include components in gas turbines, aircraft engines and exhaust systems, where high strength and oxidation resistance are important Due to resistance to high temperature corrosion and creep resistance they are used in nuclear in reactors, chemical process equipment and power generation systems. heat exchanger, and aerospace components, ensuring reliability in harsh operating conditions. Its versatility makes it ideal for industrial environments.
