Marsh Nickel Alloys, located in Canberra, Australia, stands out as a top manufacturer and supplier of high-quality **A286 Foil**. Known for their meticulous engineering and unwavering quality standards, they produce foils that offer remarkable mechanical strength along with excellent resistance to corrosion and oxidation. A286 Foil is crafted specifically for high-temperature and challenging industrial settings, making it a perfect fit for aerospace, automotive, and power generation sectors. The company’s dedication to durability, reliability, and customer satisfaction guarantees that every foil adheres to international standards. Marsh Nickel Alloys supplies high-performance materials that are essential for critical applications needing long-lasting stability and superior performance.
A286 Foil is an iron-nickel-chromium alloy that contains about 25–26% nickel, 14–15% chromium, and trace amounts of titanium and molybdenum, which boost its strength and high-temperature stability. This foil showcases impressive mechanical properties, such as high tensile strength, yield strength, and creep resistance, ensuring it maintains its structural integrity even at elevated temperatures. Its exceptional resistance to corrosion and oxidation makes it suitable for tough and demanding environments. The blend of thermal stability, toughness, and durability guarantees that A286 Foil performs reliably under continuous stress and extreme conditions in critical industrial applications.
| Standard Specification : | AMS 5525, AMS 5858 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | S | Co | Cu | Ni | Cr | P | V | Al | B |
| A286 | 0.08 max | 2 max | 1 max | 0.025 max | 1 max | 0.50 max | 24 – 27 | 13.5 – 16 | 0.025 max | 0.10 – 0.50 | 0.35 max | 0.003 – 0.010 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.92 g/cm3 | 2500-2600°F (1370-1430°C) | 90,000 psi (620MPa) | 40,000 psi (275 Mpa) | 40 % |
At Marsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of A286 Foil in Canberra, Australia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Australia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
A286 Foil finds extensive use in industries that demand high-temperature strength and corrosion resistance. Typical applications include components for gas turbines, aerospace fasteners, jet engine parts, heat exchangers, and high-performance automotive components. It’s also utilized in chemical processing and power generation equipment where thermal stability and mechanical reliability are paramount. The foil’s ability to retain its structural integrity under prolonged exposure to heat, stress, and corrosive environments makes it an ideal choice for precision components in demanding situations.
